9 bolt ???


  • Please log in to reply
14 replies to this topic

#1 cart69

cart69

    2nd Class Tech

  • Members
  • 746 posts
  • Location:Sycamore, illinois 60178
  • Year: 1970
  • Make:Pontiac
  • Model: Firebird

Posted 29 December 2003 - 10:07 PM

you have all probably heard this before but i saw the topic about the 7.5 rearend and figured i would ask the same of the 9 bolt in my 88 formula, i have a tpi 305 and 700 now and am going to an lt1 6spd will it crap out with the power gain and stick? also is there any place to get a gear for this thing?
94 Z28
hardtop
4 point roll cage
Brett Bauer custom grind blower cam
Vortech V2 supercharger
AFR heads
52mm BBK throttle body, yella terra 1.6 RR, crane ignition and coil
Hooker Coated long tubes, mufflex 4 inch y pipe, B&B catback
SLP springs, Bilstien shocks
LS1 front brakes
4:10 rearend, tubular panhard bar and box LCA's
17" ZR1 Chrome Wheels
Converted auto to M6

Mines the teal one in the middle :)



#2 formula13x

formula13x

    Master Technician

  • Members
  • 1,580 posts
  • Location:Arkansas
  • Interests:Fast cars (American Muscle), My Wife, two Daughters and Son, Serving God, Programming, Hunting, Fishing, etc...

Posted 29 December 2003 - 10:47 PM

The rear-end is the same for the 3rd gen's and the 4th gens that are already powered by that drivetrain, the diff may be different, but they seem to hold up. My rear is a 7.5in 10-bolt, just like yours, and I have the LT1 6-speed combo.
Previously Owned
97 Formula Green/Tan Leather T-Tops 6-speed - R.I.P, 89 Formula Black/Clothe T-Top LB9, 79 Z28 (lots on it) - R.I.P, 84 Trans Am blue T-Tops - Now a parts car, 85 Trans Am, 94 Firebird

Currently Owned
79 Trans Am white 6.6 liter shaker

Now faith is the substance of things hoped for, the evidence of things not seen.
www.redlineracingvideos.com | www.flinkgames.com | www.handfulmusic.com

#3 Exhumed454

Exhumed454

    Master Technician

  • Members
  • 1,149 posts
  • Interests:Chevy,Pontiac,Music and hanging out with my friends and talk about cars =]...oh yeah and hanging out with my girlfriend Angies =D

Posted 29 December 2003 - 11:54 PM

is there such thing as a 9 bolt ?....some guy keeps saying he has a 9 bolt...i have a ten bolt ph34r.gif

#4 T-Top T/A

T-Top T/A

    Orientation

  • Members
  • 24 posts
  • Location:northeast,usa
  • Interests:muscle cars

Posted 30 December 2003 - 06:45 AM

The 9 bolts are the Austrailian rears. There suppose to be alot stronger then the 10s

#5 fireduck350

fireduck350

    Master Technician

  • Members
  • 3,075 posts
  • Location:Rock Hill, SC
  • Interests:Cars, old and new, doesn't much matter to me.

Posted 30 December 2003 - 05:31 PM

T-Top T/A is correct about the 9 bolt being an Australian rear end, and it found its way into a lot of 3rd gen F-bodys. They were supposed to be strong, but the problem was and is finding replacement parts for them. If you go to http://www.9bolt.com/
there is a lot of information on there about the 9 bolt and parts for the 9 bolt, including gears.
user posted image
1990 Formula 350
1978 Trans Am w/ Olds 455
1987 IROC
1970 Monte Carlo 355
1996 Suburban
1955 Chevy 3100 2nd Series Stepside Truck

"When I die, I hope I go out like my Grandfather, in my sleep. Not like the 3 people screaming that were in the car with him."

#6 87 formula

87 formula

    Shop Janitor

  • Members
  • 84 posts
  • Location:cda idaho

Posted 31 December 2003 - 07:47 AM

I am running a borg warner 9 bolt in my camaro behind my stroker and i love it just keep in mind that there is a issue with the brakes and there was a recall for it so if you get one make sure the brakes work on it first
http://robbarnett.10...la/firebird.htm [br]

1989 GTA tpi 350 auto
1987 Formula lg4 5 speed, cam,
1984 TA 350 headers, cam, intake
1985 camaro 383, victor jr intake, elec water pump, roller cam .53/.54 lift, world sportsman II heads, accell hei, edelbrock 750 carb, headman full length headers, th-400 trans, b&m wholeshot 2400, ford 9" with 3.70 gears and a mini spool, b&m megashifter

#7 quickchicken

quickchicken

    3rd Class Tech

  • Members
  • 457 posts
  • Gender:Male
  • Location:Byhalia Ms, just south of memphis

Posted 31 December 2003 - 08:55 AM

hers all the details on the 9 bolt. it was a 3 yr run on formulas and GTAs. 87-89.
it was an option on T/As. its rumord to be as strong as or stronger than a dana 44. it IS the strongest rear GM put in an F car ever. as long as you change the fluid and use the GM additive they will last a long time.
the borg is a 7 3/4 rear instead of a 7.5 or 7.625.
the 10 bolt and the 10 bolt are very diff in every way. you cannot yse 10 bolt stuff in a 9 bolt rear.
there is a difference in brakes on thes rears. they went to te PBR brakes in 89 which are half of the 1LE system.
yes the 9 bolt is aussie , thisis why they discontinued these rears as it was more expensive to import so after 89 they dropped the rear and went back to 10 bolts but kept the PBR rear brakes which are found on the 93-97 cars as well
these rears can also be found on camaro models as well, this want a bird only option.
miles has changed the site address, it is now diffsolutions.com . the site is under construction but you can still contact him and he will answer your ques. hes a lil slow but will reply.
miles bought the rights to the brg so he could produce and sell the brg stuff inhte us. he is runningone behind his very modified 427 third gen camaro. that outta tell ya how strong the rear is!!!
83 T/A 350 T-5
89 FORMULA T-5 LB9
run it wide open till ya see god "THEN" brake !!

#8 T-Top T/A

T-Top T/A

    Orientation

  • Members
  • 24 posts
  • Location:northeast,usa
  • Interests:muscle cars

Posted 31 December 2003 - 06:29 PM

QUOTE(quickchicken @ Dec 31 2003, 07:50 AM)
it was a 3 yr run on formulas and GTAs. 87-89.
it was an option on T/As.

I have one out of an 85' Trans Am. I thought that was the first year they were introduced?

I have it for sale in the parts section

#9 quickchicken

quickchicken

    3rd Class Tech

  • Members
  • 457 posts
  • Gender:Male
  • Location:Byhalia Ms, just south of memphis

Posted 31 December 2003 - 08:33 PM

QUOTE(T-Top T/A @ Dec 31 2003, 11:24 PM)
QUOTE(quickchicken @ Dec 31 2003, 07:50 AM)
it was a 3 yr run on formulas and GTAs. 87-89.
it was an option on T/As.

I have one out of an 85' Trans Am. I thought that was the first year they were introduced?

I have it for sale in the parts section

T-top im not gonna dispute that as on miles site he has an ol hot rod article with an 85 camaro having the borg rear. but the majority of the borg rears were in 87-89 cars.
ill drop miles an E mail and see what the scoop is on its avail in 85. also Randys ring and pinion has gears but they arent borg they are yukon. i havent researched into that yet.
83 T/A 350 T-5
89 FORMULA T-5 LB9
run it wide open till ya see god "THEN" brake !!

#10 T-Top T/A

T-Top T/A

    Orientation

  • Members
  • 24 posts
  • Location:northeast,usa
  • Interests:muscle cars

Posted 01 January 2004 - 12:15 AM

Yeah, I was surprised when I pulled the rear and saw the Borg-warner stamp on it. It is a 9 bolt (non posi) Drum rear . I bought the car from the original owner, (my neighbor) and Its all Original.

The car has the LG4 engine, so Its pretty basic when It comes to performance.

Would anyone know what Gear Ratio came in these in 85? I dont want to pull the cover. Everything I read said 3.27s

#11 quickchicken

quickchicken

    3rd Class Tech

  • Members
  • 457 posts
  • Gender:Male
  • Location:Byhalia Ms, just south of memphis

Posted 01 January 2004 - 01:01 AM

you have 3 ratios that could poss be in that rear. a 2.77 ,3.08 or the 3.27. during the time the previous owner had the car the tag that is attached by the bolts must have goten pitched.
if the RPOs are on te console it will be listed there.
83 T/A 350 T-5
89 FORMULA T-5 LB9
run it wide open till ya see god "THEN" brake !!

#12 T-Top T/A

T-Top T/A

    Orientation

  • Members
  • 24 posts
  • Location:northeast,usa
  • Interests:muscle cars

Posted 01 January 2004 - 02:32 AM

Aaahhh, It does have the metal tag and It says 3.08 . I took a peice of scotch bright and cleaned it, I didnt know It had the ratio on there.

Thanks , quickchicken smile.gif

#13 Mongoose

Mongoose

    Tire Changer

  • Members
  • 118 posts
  • Location:Monroe,NC

Posted 01 January 2004 - 04:21 PM

The gear ratio will be stamped into the ring gear itself if you want to take the cover off and look to make sure. If your planning to use a 6 speed then you may want to stick with ratios of 3.45 and up. A 3.70 ratio and I believe a 4.10 was offered at one time for the 9 bolt.
Mongoose-Nature's cure for the Cobra

#14 T-Top T/A

T-Top T/A

    Orientation

  • Members
  • 24 posts
  • Location:northeast,usa
  • Interests:muscle cars

Posted 01 January 2004 - 07:41 PM

Its for sale. I already swapped in another 9 bolt (posi disk ) from a 89 formula.

#15 quickchicken

quickchicken

    3rd Class Tech

  • Members
  • 457 posts
  • Gender:Male
  • Location:Byhalia Ms, just south of memphis

Posted 02 January 2004 - 02:50 AM

QUOTE(Mongoose @ Jan 1 2004, 09:16 PM)
The gear ratio will be stamped into the ring gear itself if you want to take the cover off and look to make sure. If your planning to use a 6 speed then you may want to stick with ratios of 3.45 and up. A 3.70 ratio and I believe a 4.10 was offered at one time for the 9 bolt.

DOH1 i forgot about it being stamped into the gear! rochmond and DTS sells a 3.70 gear. Miles makes and sells upper ratio gears past 3.70-3.73 if they are needed.
83 T/A 350 T-5
89 FORMULA T-5 LB9
run it wide open till ya see god "THEN" brake !!
